The Chikin PCB AOI Machine (Automated Optical Inspection AOI) delivers next-level quality assurance for modern SMT production lines. This Automated Optical Inspection AOI system uses high-resolution multi-camera imaging and smart algorithms to inspect every detail of your PCB in real time, catching defects before they become costly failures.

1. Robust Construction with Granite The PCB AOI Machine features a premium granite base that provides exceptional vibration damping and thermal stability — ensuring consistent, high-precision imaging even in high-throughput factory environments.
2. High Accuracy Linear Guide and Ballscrew Equipped with top-grade linear guides and ballscrews, the PCB AOI Machine enables smooth, precise movement of the inspection head, delivering fast scanning speeds and reliable repeatability for accurate defect detection across large panels.
3. Advanced Detection & Automation Features While not a drilling/routing system, the PCB AOI Machine incorporates industrial-grade automation: multi-angle LED lighting for shadow-free views, automatic fiducial alignment via CCD, defect classification, repair station guidance, and low false-call AI algorithms — minimizing rework and maximizing yield.

Core Technical Highlights

• High-resolution industrial CCD cameras with multi-angle programmable lighting
• Supports 2D + optional 3D inspection modes (solder joint height/volume)
• Defect types detected: missing parts, misalignment, polarity errors, solder bridges, opens, insufficient/excess paste, tombstoning, etc.
• Inline/offline configurations with conveyor integration
• Intuitive software: Gerber/CAD import, quick program teach-in, SPC data output
• Granite base + stable motion system for vibration-free operation
• English/Chinese interface, MES/Industry 4.0 ready
• Power: 220V/380V single/3-phase
• Compact footprint with easy maintenance access

This Automated Optical Inspection AOI excels at early defect detection in SMT lines for consumer electronics, automotive, medical, and LED PCBs — reducing scrap by 50–80% and improving overall quality consistency.

Fully compatible with Chikin’s complete PCB ecosystem (drilling/routing machines, laser cutting, V-CUT, flying probe testing).

Backed by 3-year warranty and 24-hour global support — the PCB AOI Machine is your essential tool for zero-defect production in 2026.

Contact us for live AOI demo, defect sample analysis, or customized quote!
